288 FO OM3 / OM4 / OS2 / G657 MULTITUBE LOOSE ARMED EXT PE

FIBRE OPTICS  |  REINFORCED EXTERIOR MULTI-TUBE PE

288 FO OM3 / OM4 / OS2 / G657 MULTITUBE LOOSE ARMED EXT PE

Construction

Central Element:
Fibres Nb: 288
Identification: According to TIA/EIA 598A and IEC 304.
Assembly:
Protector: Glass fibre fillings.
Armour: Corrugated steel tape.
Outer cover: UNE-EN 50290-2-24 - Polyethylene for outer sheaths.
Color: Black

288 FO OM3 / OM4 / OS2 / G657 MULTITUBE LOOSE ARMED EXT PE
Weather resistant Weather resistant
Halogen free Halogen free
CPR Compilant CPR Compilant
RoHS RoHS
Low smoke opacity Low smoke opacity
CE CE
Mechanical protection Mechanical protection
Rodent protection Rodent protection
UV resistant UV resistant

Technical data / Regulations.

CPR classification: Fca
Operating temperature: -40... +70ºC
Standards:
(Sheath) UNE-EN 50288-7 - Instrumentation and control cables. / UNE-EN 50290-2-24 - Polyethylene for outer sheaths.
(Fire) UNE-EN 50575 - CPR
(Fire) UNE-EN 60754-1 (IEC 60754-1) - Halogen-free.
(Tests) IEC 60794-1-22 -
(Tests) IEC 60794-1-21 -
(Tests) IEC 60794-1 - Basic test procedures for optical cables.
(Directives) 2011/65/EU - RoHS Directive (No use of toxic products).
(System) TIA/EIA 568C - Structured Cabling System
(System) UNE-EN 50173-1 - Information technology - Generic cabling systems - Part 1: General requirements.
(System) ISO/IEC 11801 Edition 2 - Information technology -- Generic cabling.

Observations

Ceramic loose tube Ø 2.5 mm.
MULTIMODE fibers type 50/125 OM3 / OM4.
SINGLE MODE fibers type 9/125 SO2 / G657.

Applications

Gel-filled loose multitube Fiber Optic Cable filled with fiberglass strands + corrugated steel metal armor and PE outer sheath for outdoor installations.
Cables up to 288 fibers, MULTIMODE or MONOMODE type.
Resistant to the action of rodents.
