xx FO 9/125 OS2 LOOSE EXT PE

FIBRE OPTICS  |  MONOTUBE EXTERNAL PE

xx FO 9/125 OS2 LOOSE EXT PE

Construction

Central Element:
Fibres Nb: 24
Traction elements: Glass fibre fillings.
Identification: According to TIA/EIA 598A and IEC 304.
Armour: Corrugated steel tape.
Outer cover: UNE-EN 50290-2-27 - Halogen-free Z1 compound.
Color: Black

xx FO 9/125 OS2 LOOSE EXT PE
Rodent protection Rodent protection
Mechanical protection Mechanical protection
CE CE
Halogen free Halogen free
RoHS RoHS
CPR Compilant CPR Compilant
Low gas corrosiveness Low gas corrosiveness
Flame retardant Flame retardant
UV resistant UV resistant

Technical data / Regulations.

CPR classification: Fca
Operating temperature: -40... +70ºC
Standards:
(Sheath) UNE-EN 50288-7 - Instrumentation and control cables. / UNE-EN 50290-2-24 - Polyethylene for outer sheaths.
(Fire) UNE-EN 60754-1 (IEC 60754-1) - Halogen-free.
(Fire) UNE-EN 50575 - CPR
(Fire) UNE-EN 60754-2 (IEC 60754-2) - Low corrosivity of smoke.
(Fire) UNE-EN 61034 (IEC 61034) - Low smoke emission.
(Tests) IEC 60794-1 - Basic test procedures for optical cables.
(Tests) IEC 60794-1-21 -
(Tests) IEC 60794-1-22 -
(Directives) 2011/65/EU - RoHS Directive (No use of toxic products).
(System) ISO/IEC 11801 Edition 2 - Information technology -- Generic cabling.
(System) UNE-EN 50173-1 - Information technology - Generic cabling systems - Part 1: General requirements.
(System) TIA/EIA 568C - Structured Cabling System
